Snap On Im5100,Ph2045,Ph2050,Far720,Far750,Far7200,Sioux 4035 Trigger Valve Kit

$18.91 Buy It Now, Click to see shipping cost, eBay Money Back Guarantee

Seller: Top-Rated Seller ibidtobuy ✉️ (10,600) 100%, Location: Sparks, Nevada, US, Ships to: US & many other countries, Item: 134176077730 SNAP ON IM5100,PH2045,PH2050,FAR720,FAR750,FAR7200,SIOUX 4035 TRIGGER VALVE KIT. This ebay Buy-It-Now offering provides a basic 4-piece throttle valve repair kit part for Snap on PH2045, PH2050 air hammers, FAR720, FAR750, FAR7200 (air ratchets) and IM5100 impact wrenches. There may also be other Snap on tools made that this kit works to fix also. It also works with Sioux model 4035 1/2" drive tools per attached photo. If you are not not sure feel free to ask me for help. The diagrams above shows the throttle valve, a throttle valve seat and throttle/trigger spring an inlet bushing o'ring with their OEM assigned part numbers. Due to supply chain problems I may vary the colors and type of o'rings that I provide to make sure that you have enough parts for 1 complete primary tool repair and a spare throttle valve seat changeout. *Take your tools apart in advance to clean, disassemble and examine them for damage and wear first before you buy this kit from me. I will not accept any returns, refund requests or cancellation orders after this item is purchased because you found out that your tool needed other parts you would not or could buy to fix it. Choose wisely. Choose carefully. Your actions are final. This operation must be done correctly the first time as there are no extra parts if you damage the seat or tip valve when installing it. Simple kit installation instructions are herein provided below: The white seat goes in the bottom of the freshly cleaned tool handle bore first. There is a white raised circle or 360 ring on the white seat that must face up toward you. The circle ring is where the face of the red tip valve seals to prevent the tool from passing air or operating when your trigger is released. The seat is carefully installed using soft material like fuel line to push it into the tool bore. Use oil or clean vaseline or silicone grease to lube the seat and help it settle into place with the help of your fuel line to push it home. I next slide the trigger stem assembly using a flashlight to see into the bore to center the trigger stem pin locating hole (for the tip valve stem) straight down in the middle of the hole in the white tip valve seat. Make sure to locate the red/orange tip valve stem into the trigger stem hole in the trigger stem through the white seat hole while holding it with your long tweezers. Test your work by placing the narrow end of the tip valve spring onto the tip valve nub. Apply holding spring pressure on the tip valve to feel it lift when you push in on the trigger stem. Slowly and gently push the trigger to feel if you correctly located the tip valve stem into the trigger valve stem hole below. If you immediately feel tip valve movement with immediate trigger movement then you are correctly located. Now leave the tip valve spring with the narrow end on the red tip valve nub. Change the black o'ring on the steel bushing that screws into the tool handle. Screw the bushing into the tool applying pressure on the spring gently and slowly until you seat the bushing and tighten it. Avoid pulling the tool handle threads due to over-tightening of the bushing. Teflon tape or sealant should not be needed to seal. Feed some clean ATF into the air inlet before you attach the air supply. When you attach air there should be no air passing or any tool operation. Now pulling the trigger and releasing it should operate the tool and shut it off as normal operation occurs. If you have leakage or passing air the seat may be damaged during installation. One customer told me he had to put sealant on the side of the seat to seal it with the tool handle bore. There is no o'ring under the tip valve seat or on top of it by design of the Snap on product engineers. This throttle valve repair kit is my intellectual property and my design unique to only ebay and nowhere else. Anybody else on eBay or Amazon indicating to you that they are the brains behind this unique and wonderful problem solving repair kit is an intellectual property thief. This kit was created by me in 2016 and nobody but me has the installation method stated as clearly as I offer it here. The greatest difference in what I do on eBay for my customers and what my copycat competition attempt to do is pretend that they can do what I do with the same tool knowledge that I have. I am the only eBay seller who calls on his customers when they need help. My eBay customers also call me using the "Contact Seller" portal that eBay enabled for me. That is a free service that nobody offers but me. The shipping weight is 2 ounces with USPS first class. International buyers have this item shipped to Kentucky for additional processing costs through the ebay global shipping program. Condition: New, Brand: Snap on, Sioux 4035, Non-Domestic Product: No, Type: Air Tool Parts, Warranty: No, Custom Bundle: Yes, Manufacturer Part Number: PH2045,PH2050,IM5100,FAR7200,FAR720,FAR750, Bundle Listing: Yes, Country/Region of Manufacture: United States, Modified Item: No
